The Story
The new Gen2 series of Smittybilt X2O winches have been thoroughly updated with heavy-duty features for enhanced performance and comes standard with an integrated wireless remote. The new 6.6HP amphibious motor offers the highest torque in the industry and is connected to a 3-stage Planetary Gear System for increased pulling power and line speed.
All Gen2 X20 Winches come backed by a Lifetime Mechanical Warranty and a 5-Year Electrical Warranty. The COMP Series difference If you’re after a winch equipped with a state-of-the-art synthetic rope, look to the X2O COMP Series for the ultimate in pulling power. Smittybilt's exclusive Dynamic Braking System reduces drum temperatures by 66%, making it perfectly suited to operate all types of synthetic ropes.
Key Features SmittyBilt X20 Gen 2 Wireless Synthetic Rope Winch
- Waterproofing: IP68 Rating
- Rated Line Pull: 10,000Lbs (4,545kgs) Single Line
- Motor: 6.6hp Series Wound
- Control: Remote Switch, 12’ (3.7m) lead
- Gear Train: 3-Stage Planetary
- Gear Ratio: 218:1
- Clutch: Sliding Ring Gear
- Brake: Automatic Out-Of-Drum
- Drum Size: Diameter 2.5”Cable: 98.5’ 3/8” Diameter
- Cable Type: Synthetic Rope
- Fairlead: Hawse Remote
- Control: Included Integrated Wireless Remote Recommended Battery: 650CCA Minimum for Winching
- Battery Leads: 25mm2, 72”(1.83m)1
- Finish: Textured Black
- Weight: 67.0Lbs (30.4Kgs)
- Mounting Bolt Pattern: 10.0” x 4.50”
- Overall Dimensions: (L x W x H) 22.3” x 5.4” x 9.4
